Description
This OEM-quality Waterway Executive 48 frame circulation pump delivers reliable 5.0hp performance with dual-speed operation for your portable spa system. Built with integrated thermal protection, this motor safeguards against overheating to maximize operational longevity.
Key Product Specifications:
- Designed around the Executive 48-frame motor platform for optimal compatibility
- Oversized 6-1/2" diameter hydraulic assembly delivers superior head pressure performance
- 2" inlet and outlet connections for efficient water flow
- 360-degree rotatable hydraulic end simplifies installation in tight spaces
- Built-in thermal safeguard prevents motor damage from overheating conditions
- Unit Dimensions (Height x Width x Length): 8.34" x 8.13" x 15.20"
- Part of a complete series ranging from 1 to 4.5Hp in single or dual speed configurations
Technical Specifications:
| Complete Pump Type | Portable Spa Pump |
| Speed | 2 Speed (2-Spd) |
| Motor Voltage | 115v |
| Drain Plug Location | 3,6,9 o`clock |
| Pump to Motor Foot Types | 4a |
| Suction Style | Center |
| Suction Connection (Physical Dimension) | 3-1/16"od |
| Suction Connection Type | Male Buttr |
