Pump Wet Ends and Related Parts

This Wavemaster 3000 Face Plate O-Ring Is 5 1/8" Inside Diameter and is 1/8" Thick.   For other parts related to this part see the below links:

This part is a replacement wear ring for Wavemaster 5000 Pump Impellers with a 1 3/4" Eye.. The ring measures about 1 3/4" inside the wear ring and 2 3/16" at the widest part and about 3/4" tall..   The below List is other parts related to this...

This part is a replacement wear ring for Wavemaster 3000 Pump Impellers with a 1 3/4" Eye.. The ring measures about 1 3/4" inside the wear ring and 2 3/16" at the widest part and about 3/4" tall.. For Other related parts see the below links:  ...

This is a 1HP Impeller for a Wavemaster 3000 Code 04184 48 Frame Side Discharge pump. This Impeller fits between the Face and the Volute of a Wavemaster 3000 Series Wet End. I would advise replacing the Seal when you replace the Impeller. This Impeller...

This kit is a that Fits Watkins, Vendor #04184, found under the name Wavemaster 3000 numbers Features (1) Seal, seal tool (2) Bearings and (1) 1/2 Oz Tube of The Professor's Silly Juice a Specially Formulated for Hot Tubs Silicon Sealer.   Note:...

This kit is a that Fits Watkins, Vendor #04184, found under the name Wavemaster 3000 numbers Features (1) Seal, seal tool (1) Bearing and (1) 1/2 Oz Tube of The Professor's Silly Juice a Specially Formulated for Hot Tubs Silicon Sealer.   Note:...

This kit is a that Fits Watkins, Vendor #04184, found under the name Wavemaster 3000 numbers Features (1) Seal, seal tool and (1) 1/2 Oz Tube of The Professor's Silly Juice a Specially Formulated for Hot Tubs Silicon Sealer.   Note: Watkins used...

Watkins Vendor Code 4081 Wavemaster, 4000, 6000, 7000, 8000, 8200, 9000, 9200... 48Frame Pump Face O-Ring Only fits around the Face of this Pump Face...

This Part is a 2 1/8" wear ring that is used between the impeller and the wet end face on Watkins Vendor Code # 4081, Wavemaster, 4000, 6000, 7000, 8000, 8200, 9000, 9200.. This wear ring serves as a seal between the suction and pressure sides of the...

  This is a 1HP Seal & Impeller Kit for a Watkins 37334 Vendor Code# 4081 Pump with a 2 1/8" Eye with 1/4" Vane Width and 3 7/8" OD for an Wavemaster 48 1.0HP Motor would be about 7-8.0 Amps on high speed at 230V or 11-12.0 Amps at...

This part is a 3HP Sta-Rite DJ Dura-Jet Pump Impeller.. This impeller will usually have the number 17400-0135 cast into the back and will measure about 4 1/8" wide with an eye width of 1 3/4" and a vane width of 1/2".. This can be found on motors with an...

This item is a 1.0HP Waterway HiFlo Pump Impeller "C" Kit which included the Seal Kit as well.. If Your motor is 115V the amperage would be about 12 Amp if 230V it would be about 8 amps..Closed face impeller made for the HiFlo side discharge...
